5.0 INSTALLATION AND FIXING
2
FIL.SILOTOP_zero.--.M.A4.0722.EN Issue: A4
07.22
23
CODES DESCRIPTION
01 MANUAL BALL VALVE (NOT SUPPLIED BY WAM
®
)
02 RELIEF VALVE (NOT SUPPLIED BY WAM
®
)
03 TANK
04 1” QUICK DISCHARGE VALVE 1”
05 COIL
06 AIR OUTLET
07 CONDENSATION DRAIN
ENTRATA ARIA
USCITA ARIA
04
05
01
06
03
07
02
AIR OUTLET
AIR INLET
