System tubing connections B-1
B External Connections
A Waters Technical Service representative unpacks and installs your
ACQUITY UPLC I-Class system modules.
See also: Configuring ACQUITY UPLC I-Class System Components
(P/N 715003144)
Requirements:
• Contact Waters Technical Service before moving the ACQUITY
UPLC I-Class system modules.
• If you must transport a system component, or remove it from
service, contact Waters Technical Service for recommended
cleaning, flushing, and packaging procedures.
System tubing connections
The system’s external tubing connections for solvent flow and drainage are
shown below.
Warning: To avoid back injuries, do not attempt to lift the system
modules without assistance.
Contents:
Topic Page
System tubing connections B-1
External wiring connections B-4
Signal connections B-5
Connecting to the electricity source B-11
