Section 3
Auto-Zone CV & CV-EX
3-2 Programming
System Manager LED Indicators
There are three LED indicators located on the right hand side of the System Manager.
The top LED indicates an Alarm condition if the Manager detects an alarm condition
while polling the system.
The middle LED is active during actual communications or packet transfers. This LED
will normally "flicker" and not remain on constantly.
The bottom LED is reserved for Override indications and is not used for this application
of the System Manager.
Main Screen
The Auto-Zone System Manager is your direct link to the status and setpoints of any
Auto-Zone component on your communications loop. With the System Manager, you can
view any temperature or output condition and change any setpoint to fine tune the
operations of the total system. All keypad operations are simple and straight-forward,
utilizing non-cryptic plain English messages. The System Manager automatically detects
the type of unit that has been selected, and displays the appropriate status and setpoint
screens. The attractive plastic case of the System Manager allows for placement in any
area of your building.
The remainder of this document will lead the user through the system menus and keypad
operation.
All user functions are accessed by pressing the Menu button. Once the button is pressed,
the Main User Menu is displayed.
vX.XX
Friday Operations
03/15/02 09:46 AM
Outdoor Air 78.0°F
To Next Page
