Auto-Zone CV & CV-EX
Section 4
Start-Up and Troubleshooting 4-9
CV And CV-EX System
Communications Checklist
CV & CV-EX Systems
CV Units on each loop are correctly addressed from 1 to 30
Power has been cycled after changing addresses
There are no duplicate addresses on the loop
CommLink is connected to the communications loop
All CV Controllers are connected to the communication loop
System Manager is connected to the communications loop
All communication wiring is landed correctly, T to T, R to R and SHLD to SHLD
CommLink is set for single loop operation
CV Controllers are wired to 24 Volt AC power supply
CommLink is wired to 24 Volt AC power supply
All 24 VAC power wiring is landed correctly, 24VAC to 24VAC and GND to GND
CommLink is powered up
CV Units are powered up
System Manager is powered up
Additional Checks For The CV-EX System
MiniLinks are correctly addressed from 1 to 4
MiniLink Power has been cycled after changing addresses
There are no duplicate addresses on the loop
All CV Controllers are connected to the Local communications loop
CommLink is connected to the Network communications loop only
System Manager is connected to the Local communications loop
Optional Equipment
Personal computer is correctly connected to the CommLink
Prism™ software installed on personal computer
Remote Link is correctly connected to the CommLink
Remote Link connected to a working phone line
