Section 3
Auto-Zone CV & CV-EX
3-16 Programming
CV Controller Setpoints
Line 1 displays CVAHU Setpoints message for identification only.
Setpoint Screen #1
Setpoint Screen #2
CVAHU Setpoints
Occupied Setpoints
Cooling Setpt: 75°F
Heating Setpt: 72°F
The Occupied Heating and Cooling Setpoints are entered on
this screen. The Heating Setpoint should always be at least one
degree below the Cooling Setpoint, or the CVAHU will not
accept the new values.
Minimum Default Maximum
Cooling Setpoint 50°F 75°F 90°F
Heating Setpoint 50°F 72°F 90°F
CVAHU Setpoints
Unoccupied Setpoints
Cool Setup...: 10°F
Heat Setback.: -10°F
The Unoccupied Heating and Cooling Setup values are
entered on this screen. The Occupied Cooling Setpoint will be
increased by the Cooling Setup during Unoccupied Mode and
the Heating Setpoint will be decreased by the Heating Setback.
Minimum Default Maximum
Cooling Setup 0°F 10°F 30°F
Heating Setback 0°F -10°F -30°F
