Section 4
Auto-Zone CV & CV-EX
4-14 Start-Up and Troubleshooting
Startup & Commissioning
Commissioning the system correctly is one of the most important steps in getting a
system installed and functioning with the least amount of problems and in the shortest
length of time.
Procedures
The following is a list of items and reminders that are essential to the successful commis-
sioning of your system. Some of these items have already been discussed in this manual
and are repeated to confirm correct procedures. Familiarize yourself with this installation
manual and system wiring diagrams before installing!
1) Check to see if you have all the correct components for your installation.
2) Establish the location for the CommLink Interface first. This is where your
communication cable will begin for the CV, & CV-EX systems.
3) Layout your communication wiring per the instructions in the previous por-
tion of this manual. For CV Systems it is only one loop. For CV-EX Systems
there are two communication loops:
4) The Network Loop - This loop originates at the CommLink and interconnects
MiniLinks together.
5) The Local Loop – This loop originates at the MiniLink. All controllers and the
System Manager are connected to this loop.
6) Tip: Using the Auto-Zone color-coded and labeled Communication Cable in-
sures a quality installation. It also makes your installation much easier and
less likely to have communications wiring errors!
7) Always refer to the CV and CV-EX Wiring Diagrams for specific wiring
details. Communication cable must always be shielded – no exceptions!
8) Mount controllers in appropriate locations according to their operating speci-
fication.
9) Use the CV and CV-EX Worksheets included in the back of this section or the
ones included with the submittal package to document unit location, descrip-
tions, addressing and setup. Address controllers according to location and ad-
dressing instructions located in this system manual.
