THEORY
OF
OPERATION
PLL #1
The purpose of PLL #1
is
to generate a
CW signal which changes in 1 kHz steps
from 10 .000 to
9
.001 MHz as
the
front
panel
frequency selector is switched
from .000 MHz to .999 MHz . This signal
will be used as
a
reference signal
for
PLL #4 .
Figure 3-2 shows a simplified block dia-
gram of PLL #1 . It consists of a voltage
controlledoscillator capable of frequen-
cies from 9 to 10 MHz, a phase detector
and a jN counter
.

A sample of the output
signal from
the
VCO
is fed to a program-
mable
counter
.
The divisor of the
counter is controlled by the three front
panel kHz selector switches .

The output
from the counter is fed to a phase de-
tectorwhere it is compared to a 1 kHz
3-4
/NP!/T
PROG-
l
MHz
XTAL
REF
PLL #2
Figure 3-3 . PLL #2
crystal reference signal .

If
the two
input signals
to
the
phase detector
are
not the
same frequency, an error signal
is produced .

This error voltage corrects
the frequency of
the VCO

until
the
phase detector
input
from
the counter is
exactly 1
kHz .
The purpose of PLL #2 is to generate a
CW signal which changes in 1 MHz steps
from 1448 to 1487 MHz
when the front
panel frequencyselector is switched
from
000 . to 039 . MHz . These CW
steps are
then repeated every 40 MHz
throughout
the entire 0 to 520 MHz range . Use of
this signal to control the Wide Oscil-
lator willbe discussed in the descrip-
tion
of PLL
#4 .
MIXER

OUTPUT
OUTPUT

FREQ,
MHz

iYlNz
000 .
- 8
/448
00/ .
9 _
- 9 /449
r
-s-
s ___Sr-
039 . 47
- 47 1487
040 9
B /448
04/ 9
9 /449
