Wavetek 3000 - P-C 4806-01-4004

REFERENCE
DESIGNATORS PART DESCRIPTION
ORIG-MFGR-PART-NO MFGR WAVETEK NO . CITY
Cl C29 C30 C31 CAP,F .T .,6 .8PF 54-794-010-6892 SPEC
1510-30-1689 4
CF102-R68
C10 C4 CAP,CER,i50PF,1KV 60Ui51M
MDC 1510-10-1151 2
CD102-115
C11 . CAP,VARI,7.35PF,250V 7STRIKO-02
STR 1510-70-0350 1
CV101-035
C12+ CAP,MICA,27PF CM05ED270JO3 ARC 1510-50-0270
1
C13 CAP,MICA,470PF,500V DM15-471J ARC 1510-50-0471 1
CM101-147
C15 C18 CAP,TANT,10MF,25V 162p10bX0025DD2 SPR 1510-21-7100 2
CE120-010
Cib C1'7 CAP,CER,F .T . 1000PF 54-794-010-102P SPEC
1510-30-8102 2
CF112-210
C19
C?4 C25 C26 C27 CAP,CER, .OIMF,100V 68U103M MDC 1510-10-2103
9
C3 C5 C8 C9 CD103-310
C2 CAP,CER,75PF,IKV IOTCU-G75 SPR 1510-10-3750 1
CD104-075
C20 CAP,CER, .OOIMFD,IKV SGAD10 SPR 1510-10-1102 1
CD102-210
C21 CAP,MICA,IOOPF,500V DM15-IOIJ C-D 1510-50-0101 1
CMIOI-110
:%? C28 CAP,CER,20PF,lKV
6000G200J MDC 1510-10-0200 2 .
CDIOI-020
WAVETEK
TITLE
ASSEMBLY NO . REV
FI'I REF, M29-2 1114-00-0016 G
PARTS LIST
PAGE : i
REFERENCE DESIGNATORS PART DESCRIPTION ORIG-MFGR-FART-NO MFGR WAVETEK
NO . OTY
C6 CAP,CER,3000PF,lKV 5GA-D30 SPR 1510-10-1302
1
CD102-230
C7 CAP,CER,68PF,IKV 68U2J680J MDC 1510-10-3680 1
CD104-068
CR1 CR10 CR11 DIODE DR000-001 IN4004 P-C 4806-01-4004 3
CR2 CR7 CRS
CR9 DIODE D0000-011 FD-6666
FCD 4807-02-0003 4
CR3 CR4 CR5 CR6 DIODE D0000-010 FD777 FCD 4807-02-0002
4
IC03 DUAL DIFF AMP CA3102AE RCA 7000-31-0200 1
IC1 IC2
IC,8 PIN,I0000-008 LM301-AN NAT
7000-03-0100 2
J1 CONN JFOOO-005 37JR116-1 S-C 2110-03-0002 1
L01 L02
TOROID LA009-010-1
HYT 1810-05-0004 2
01 TRANS OB000-011 TD401 SPR 4902-00-4010
1
010 07 TRANS
GA051-390 2N5139
NAT 4901-05-1390 2
02 TRANS OBOOO-009 MPS3702 NAT 4902-03-7020 1
03 TRANS OB000-010 TD101 SPR
4902-00-1010 1
04 TRANS GA039-040 2N3904 NAT 4901-03
9040
1
05 TRANS GA039-060
2N3906
T-I 4901-03-9060 1
WAVETEK
TITLE ASSEMBLY NO .
REV
FM REF,M29-2 1114-00-0016 G
PARTS LIST
PAGE
:
2
