Weber E-330 User Manual

24
mAINTENANcE
BURNER TUBES CLEANING OR REPLACEMENT
You will need: Phillips screwdriver, flathead screwdriver, and 5/16" nut-driver.
A) Your Weber
®
gas barbecue must be OFF and cool.
B) Turn gas OFF at source.
C) Remove cookbox components - warming rack, grates and Flavorizer
®
bars. (Heat
deflectors do not need to be removed.)
Control Panel Removal
To remove control panel:
A) Locate door pin release in door assembly. Using a screwdriver, push down on door
pin release (1) until door detaches from frame assembly. Pull top of door away from
frame assembly (2) and lift door off bottom adjustable hinge pin.
B) Remove control knobs, igniter button, igniter retention nut, and battery (3).
C) Remove screws from wind deflector (4) located underneath the control panel with a
Phillips screwdriver.
D) Tilt end of wind deflector down and slide away to remove (5).
E) Remove igniter module from control panel (6) and remove all four wires from
module.
F) Remove screws from underside of control panel with Phillips screwdriver (7).
G) Lift control panel up slightly, tilt up front edge and gently lift up and away (8).
3
4
5
6
7
8
1
2

Weber E-330 Specifications

General

Main Burners	3
Total Cooking Area	637 sq in
Main Burner BTU	32, 000 BTU
Side Burner BTU	12, 000 BTU
Weight	180 lbs
Grill Type	Gas Grill
Primary Cooking Area	507 sq in
Warming Rack Area	130 sq in
Grates Material	Porcelain-enameled cast iron
Fuel Type	Liquid Propane
Ignition System	Electronic
Grill Material	Porcelain-enameled
Dimensions	60 x 27 x 48 inches
Sear Station Burner BTU	7, 500 BTU
