Weber Summit Series Installation And Operating Guide

1 Cover
2 Hinge rod/Acorn nut
3 Windshield
4 Wire grate
5 Burner cap
6 Burner ring
7 Burner head
8 Electrode
9 Burner base
10 Top panel
11 Side burner frame
12 1/8 NPT x 3/8 inch
SAE flare fitting
13 3/8 inch SAE flare
fitting x 3/8 inch SAE
flare fitting union
14 Rigid tube long
15 Igniter
16 Rigid tube short
17 Side burner valve and
mounting nut
18 Side burner knob
19 Sleeve
20 Front panel
SIDE BURNER EXPLODED VIEW
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
