Weber Summit Series Installation And Operating Guide

4
BUILT-IN STRUCTURE
CUTOUT DIMENSIONS
Side Burner Tolerances
A10
3
⁄4”
B4
1
⁄2”
C 24”
WT 40
DIMENSIONS
+
3
⁄16”
- 0
+
3
⁄32”
- 0
+
3
⁄16”
-0
BUILT-IN CUTOUT DIMENSIONS
BUILT-IN STRUCTURE
SLEEVE DIMENSIONS
Side burner Tolerances
A10
19
⁄32”
B4
9
⁄64”
C23
25
⁄32”
WT 40
DIMENSIONS
+
1
⁄4”
- 0
+
1
⁄8”
- 0
+
1
⁄4”
-0
BUILT-IN INSULATED SLEEVE
DIMENSIONS
Weight (expressed in pounds) represents the total weight
of the sleeve and the cooking unit and does not include
the permanent structure housing the sleeve.
Specified sleeve dimensions “A through C” reflect the
dimension to the mounting surface of the trim excluding
the overhang.
WARNING: Air holes must be provided in the
structure at the top and bottom to provide ventilation
in the event of a gas leak.
Air holes can be located in a low visibility area and should
be protected by screening material to prevent rodents and
insects from entering the structure. Air holes will also help
dry moisture.
If you are going to use a rotisserie with the cooking
module, make sure you space the side burner far enough
away to facilitate its use.
Before installing the sleeve, lay a bead of silicon sealant
around the top perimeter and front sides of the structure
in the areas that the flanges of the sleeve will rest. This
will prevent moisture seepage. The sealant you use must
have a temperature rating above 120°F. If necessary,
caulk between the flange of the sleeve and finished
countertop surface.
WARNING: All countertop finished surfaces must be
constructed of a noncombustible material.
Countertop
Silicon sealant
Figure 3
Figure 4
Figure 5
Weight (expressed in pounds) represents the total weight
of the sleeve and the cooking unit and does not include
the permanent structure housing the sleeve.
The sleeve must be supported from the bottom.
Recommended cutout dimensions “A through C” include a
nominal clearance dimension to facilitate installation. Any
additional clearance must be within tolerances shown or fit-
up of sleeve and built-in structure may be adversely affected.
A
B
C
DEPTH
HEIGHT
WIDTH
All dimensions are to finished surfaces.
