WEBTEC HPM - Memory function AUTO TRIGGER

112 V2.0/02.11
Recordingmeasuredvalues
MemoryfunctionAUTOTRIGGER
The function Auto Trigger documents the process of recording meas-
ured values triggered by a dened start signal (for example, pressure
on channel 2 → 125 bar). In response, a sequence of measured values
are automatically recorded until the previously set measurement time
expires.
Time-dependent functions (for example, making operations or produc-
tion cycles) are measured when recording measured values.
The following parameters must be set:
Menu Setting/
pre-selection
Values Notes
TIME UNIT> sec, hrs h Pre-selected time unit
(trigger/pre-trigger)
DURATION> Number 100 Recording time
PRE
TRIGGER>
Number 1 Pre-trigger time (time
before the trigger signal)
TRIGGER> IN p1 Starting-point measuring
channel
LEVEL> Number 125 bar Start point value
TRIG
SLOPE>
▲ ▼ ▲ Ascending or descending
edge
AUTO
READY>
YES, NO YES Recording of measured
values is repeated auto-
matically
