WEBTEC HPM - Determining the number of recording intervals

130 V2.0/02.11
Descriptionofthememoryfunctions
1.Determiningthenumberofrecordingintervals:
Channels Measured
variable
Number
ofmeasured
values
Numberofrecording
intervals
120.000 ÷ measurement
values = number of
recording intervals
Example ➀
4 (SCPT) °C
bar
Measured
values
4
4
8 120.000 ÷ 8 = 15.000
Example ➁
2 (SCPT)
1 (SCFT)
1 (SCRPM)
°C
bar
L/min
RPM
Measured
values
2
2
1
1
6 120.000 ÷ 6 = 20.000
