WEG CFW100 - Page 13

General Information
English
Digital
inputs
(DI1 to DI4)
Sources for electronics and interfaces
between power and control
PC
POWER
Single-phase
rectifier
Filter
Motor
U/T1
V/T2
W/T3
Inverter
with IGBT
transistors
Power
supply
L1/L
L2/N
(SUPERDRIVE
G2, WLP)
RS-485
USB
Adapter
DC link
capacitor
bank
HMI
Control
board
with CPU
16 bits
Flash Memory
Module
Bluetooth
CANopen/
DeviceNet
Bluetooth
adapter
HMI
(remote)
PE
PE
Accessories
Analog input
and relay
output
Converter
USB-RS485
CONTROL
Figure 2.1: CFW100 block diagram
