Installation and Connection
English
ATTENTION!
When installing two or more inverters vertically, respect the minimum clearance
A + B (as shown in Figure B2 on page 124) and provide an air deflecting plate
so that the heat rising up from the lower inverter does not affect the top inverter.
Provide independent conduits for the physical separation of signal, control and
power cables (refer to section 3.2 ELECTRICAL INSTALLATION on page 16).
3.1.2.1 Cabinet Mounting
For inverters installed inside cabinets or metallic boxes, provide proper exhaustion, so that the
temperature remains within the allowed range. Refer to the dissipated powers in Table B2 on
page 122.
As a reference, Table 3.1 on page 15 shows the air flow of rated ventilation for each model.
Cooling Method: internal fan with air flow upwards.
Tab l e 3 .1: Air flow of the internal fan
Model CFM I/s m
3
/min
B 6.00 2.83 0.17
C 7.73 3.65 0.22
3.1.2.2 Surface Mounting
Figure B2 on page 124 illustrates the CFW100 installation procedure for surface mounting, using
the mounting accessory with screws (for further information, refer to chapter 7 ACCESSORIES
on page 39).
3.1.2.3 DIN-Rail Mounting
The CFW inverter can also be mounted directly on a 35mm-rail, in accordance with DIN EM
50.022. For further details, refer to Figure B2 on page 124.
