DETAILED PARAMETER DESCRIPTION
e) N* > Nx f) Is < Ix
ON
OFF
Nx (P0288)
N*
Relay/
Transistor
OFF
Time
Time
OFF
ONON
Ix (P0290)
Is
Relay/
Transistor
Time
Time
g) N > Nx and Nt > Nx h) No external Fault
ON
OFFOFF
Nx (P0288)
Nt N
Relay/
Transistor
Time
Time
OFFON
Relay/
Transistor
Time
Time
Without fault
With fault
i) 4 to 20 mA reference j) N = 0
OFF
ONON
Relay/
Transistor
Time
Time
Ref.
2 mA
ON
OFFOFF
Relay/
Transistor
Time
Time
Speed
P0291
k) Process variable X > VPx l) Pre-charge OK
ON
OFFOFF
VPx (P0533)
Process
Variable
Relay/
Transistor
Time
Time
OFF
ONON
Relay/
Transistor
Time
Time
DC Link
Pre-charge
level
MVW3000 | 5-63
