Page #7 background imageLoading...
Page #7 background image
1
QUICK REFERENCE OF PARAMETERS AND FAULTS
1 QUICK REFERENCE OF PARAMETERS AND FAULTS
Software: V1.3X
Application:
Model:
Serial number:
Responsible:
Date: / / .
1.1 PARAMETERS
Param. Description Adjustable range Factory
setting
Page
P0000 Parameter access password 0 to 999 0 5-1
P0001 Motor speed reference Read-only parameter (rpm) - 5-2
P0002 Motor speed Read-only parameter (rpm) - 5-2
P0003 Motor Current Read-only parameter (A) - 5-2
P0005 Motor Frequency Read-only parameter (Hz) - 5-2
P0006 VFD Status - - 5-2
P0009 Motor Torque Read-only parameter (%) - 5-4
P0010 Inverter output power Read-only parameter (kW) - 5-5
P0012 Digital inputs DI1 to DI10 status - - 5-5
P0013 Digital outputs DO1 to RL5 status - - 5-5
P0018 Value of analog input AI1 (single-pole,
MVC4 board)
Read-only parameter (%) - 5-6
P0019 Value of analog input AI2 (two-pole,
MVC4 board)
Read-only parameter (%) - 5-6
P0020 Value of analog input AI3 (two-pole, EBB
board)
Read-only parameter (%) - 5-6
P0021 Value of analog input AI4 (two-pole, EBA
board)
Read-only parameter (%) - 5-6
P0022 Temperature on MVC3 board Read-only parameter (
C) - 5-6
P0023 MVC4 board software version - - 5-6
P0025 Iv Read-only parameter (A) - 5-6
P0026 Iw - - 5-6
P0027 Iu - - 5-6
P0028 Value of analog input AI5 (isolated
single-pole, MVC4 board)
Read-only parameter (%) - 5-6
P0030 Temperature register channel 1 Read-only parameter (
C) - 5-7
P0031 Temperature register channel 2 Read-only parameter (
C) - 5-7
P0032 Temperature register channel 3 Read-only parameter (
C) - 5-7
P0033 Temperature register channel 4 Read-only parameter (
C) - 5-7
P0034 Temperature register channel 5 Read-only parameter (
C)
- 5-7
P0035 Temperature register channel 6 Read-only parameter (
C) - 5-7
MVW3000 | 1-1
