5
DETAILED PARAMETER DESCRIPTION
P0030 - Temperature register channel 1
P0031 - Temperature register channel 2
P0032 - Temperature register channel 3
P0033 - Temperature register channel 4
P0034 - Temperature register channel 5
P0035 - Temperature register channel 6
P0036 - Temperature register channel 7
P0037 - Temperature register channel 8
Acesso: Menu → Status → Measurements → Temperature
Description:
For these parameters indicate the motor temperature properly, the temperature control module (Tecsystem,
Pextron) must be installed observing the recommendations contained in its manual.
The overtemperature alarm and fault levels are configured directly on the temperature control module according
to its manual.
The module serial configuration must be set as follows:
Baudrate: 2400 bps
Slave address: 1
Parity: even
Stop bit: 1
✓
NOTE!
This parameter is only visible on the HMI when: the Temperature Register function is active,
P0315 = 1 (Modbus serial for Tecsystem module) or P0315 = 2 (Modbus Serial for Pextron mod-
ule).
P0038 - Encoder speed
Acesso: Menu → Status → Measurements → Speed
Description:
It indicates the encoder actual speed, in revolutions per minute (rpm), through a 0.1 second filter.
P0040 - Value of process variable (PID)
Acesso: Menu → Status → Inverter → Status
Description:
It indicates the value of the process variable in % (factory setting) used as the PID feedback.
The scale can be changed through P0528 and P0529.
See the detailed description in Section 6.1 PID REGULATOR on page 6-1.
✓
NOTE!
This parameter is only visible on the HMI when: the PID function is active, P0203 = 1 (PID regulator).
MVW3000 | 5-7
