5
DETAILED PARAMETER DESCRIPTION
Table 5.17: Guided start-up routine
Parameter
Description
P0400
Motor rated voltage
P0401
Motor rated current
P0402
Motor rated speed
P0403
Motor Rated Freq
P0404
Not implanted in this software version
P0406
Not implanted in this software version
P0408
Run Self-tuning
0 = Inactive
1 = Autogain (automatic calculation of the gains of the
controllers)
P0409
Motor stator resistance Rs
P0410
Motor magnetization current (Imr)
P0411
Motor Flux Leakage Inductance
P0412
Lr/Rr Constant
P0413
Tm Time Constant
Refer to the specific description of each parameter for more details.
Parameters from P0409 to P0413 correspond to motor internal parameters, and they must be programmed
according to the motor nameplate data.
The values programmed at P0409 to P0413 must be different from zero; otherwise, the inverter will not leave
the guided start-up routine.
The configuration of this parameter must be done under the orientation of WEG technical assistance.
Table 5.18: Control Type
P0202 Function
0
V/F 60 Hz
1
V/F 50 Hz
2
Adjustable V/F (refer to P0142 to P0146)
3
Sensorless Vector
4
Vector with Encoder
✓
NOTE!
This parameter can be changed only with the motor stopped.
P0203 - Special function selection
Adjustable range: 0 to 1 Factory setting: 0
Acesso: Menu → Configurations → Functions → PID
Description:
It defines the special function selection.
For the PID regulator special function, refer to the detailed description of the related parameters (P0520 to
P0535).
When P0203 is changed to 1, P0265 is automatically changed to 15 - Manual/Automatic.
Table 5.19: Special function selection
P0203 Function
0
None
1
PID regulator
MVW3000 | 5-31
