WEG MVW3000 User Manual

5
DETAILED PARAMETER DESCRIPTION
✓
NOTE!
This parameter can be changed only with the motor stopped.
P0401 - Motor rated current
Adjustable range: 0.1 to 3705.0 A Factory setting: 140.0 A
Acesso: Menu → Configurations → Nominal data → Motor
Description:
Set according to the motor nameplate data, taking into account the motor voltage.
✓
NOTE!
This parameter can be changed only with the motor stopped.
P0402 - Motor rated speed
Adjustable range: 1 to 7200 rpm Factory setting: 1796 rpm
Acesso: Menu → Configurations → Nominal data → Motor
Description:
Set this parameter according to the motor nameplate data.
The range for V/F is from 0 to 7200 rpm.
✓
NOTE!
This parameter can be changed only with the motor stopped.
P0403 - Motor Rated Freq
Adjustable range: 1 to 120 Hz Factory setting: 60 Hz
Acesso: Menu → Configurations → Nominal data → Motor
Description:
Set this parameter according to the motor nameplate data.
The range for V/F is from 1 to 120 Hz.
✓
NOTE!
This parameter can be changed only with the motor stopped.
P0405 - Speed sensor data (encoder)
Adjustable range: 100 to 9999 PPR Factory setting: 1024 PPR
Acesso: Menu → Configurations → Nominal data → Motor
Description:
Program the number of pulses per revolution (ppr) of the used incremental encoder when P0202 = 4 (Vector
with Encoder).
MVW3000 | 5-72
