HMI OPERATION
4.6 HELP FUNCTION
The HMI has an on-line help function. For the parameters and situations where the help is available, an indication
in form of a question mark is presented at the top strip of the HMI display (refer to Figure 4.1 on page 4-1). By
means of the help key
the user gets access to the explanatory text of the corresponding parameter or function,
as shown in the Figure 4.13 on page 4-12.
Exit 13:38
Sub
LOC
0rpm
P1550
Ratio of the input current CTs
It sets the the ratio of the
current transformers used in the
measurement of the input current.
Set according to the current
transformer nameplate data.
>
>
Figure 4.13: Help function visualization mode
MVW3000 | 4-12
To Next Page
