WEG MVW3000 User Manual

1
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0036 Temperature register channel 7 Read-only parameter (
◦
C) - 5-7
P0037 Temperature register channel 8 Read-only parameter (
◦
C) - 5-7
P0038 Encoder speed Read-only parameter (rpm) - 5-7
P0040 Value of process variable (PID) Read-only parameter (%) - 5-7
P0041 Active redundant ventilation set 0 = Set A is active
1 = Set B is active
2 = Set A is active - Set B has failed
3 = Set B is active - Set A has failed
4 = Set A is active - Sets A and B have failed
5 = Set B is active - Sets A and B have failed
6 = Set A automatic test
7 = Set B automatic test
- 5-8
P0042 Time powered counter Read-only parameter (h) - 5-8
P0043 Time enabled counter Read-only parameter (h) - 5-8
P0045 HMI software version - - 5-8
P0066 MVC3 board software version - - 5-9
P0067 Error Register 1 to 100 1 5-9
P0068 Present Error - - 5-9
P0070 Status of the MVC3 board digital inputs
DI1, DI2, ..., DI16
- - 5-9
P0071 Status of MVC3 board relay digital out-
puts RL1 to RL8
- - 5-10
P0076 i x t Overload Read-only parameter (%) - 5-10
P0077 Motor field current Read-only parameter (A) - 5-10
P0079 Synchronous motor shaft position Read-only parameter (
◦
) - 5-10
P0080 Date (dd/mm/yy) - - 5-11
P0081 Hour (24hs) - - 5-11
P0100 Acceleration time 0.0 to 999.0 s 100.0 s 5-11
P0101 Deceleration time 0.0 to 999.0 s 180.0 s 5-11
P0102 Acceleration time 2nd ramp 0.0 to 999.0 s 100.0 s 5-11
P0103 Deceleration time 2nd ramp 0.0 to 999.0 s 180.0 s 5-11
P0104 S Ramp 0.0 to 100.0 % 0.0 % 5-12
P0119 Reactive power reference for the power
factor control
-99.99 to 99.99 % 0.00 % 5-12
P0120 Reference Backup 0 = Inactive
1 = Active
1 5-13
P0121 HMI speed reference 0 to 7200 rpm 90 rpm 5-13
P0122
(2)
Speed reference for JOG or JOG+ 0 to 8192 rpm 150 rpm 5-13
P0123
(2)
Speed reference for JOG- 0 to 8192 rpm 150 rpm 5-13
P0124
(2)
Multispeed reference 1 0 to 4095 rpm 90 rpm 5-14
P0125
(2)
Multispeed reference 2 0 to 4095 rpm 300 rpm 5-14
P0126
(2)
Multispeed reference 3 0 to 4095 rpm 600 rpm 5-14
P0127
(2)
Multispeed reference 4 0 to 4095 rpm 900 rpm 5-14
MVW3000 | 1-2
