QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0128
(2)
Multispeed reference 5 0 to 4095 rpm 1200 rpm 5-14
P0129
(2)
Multispeed reference 6 0 to 4095 rpm 1500 rpm 5-14
P0130
(2)
Multispeed reference 7 0 to 4095 rpm 1800 rpm 5-14
P0131
(2)
Multispeed reference 8 0 to 4095 rpm 1650 rpm 5-14
P0132 Maximum overspeed level 0 to 100 % 10 % 5-15
P0133
(2)
Minimum speed reference 0 to 7200 rpm 90 rpm 5-16
P0134
(2)
Maximum speed reference 0 to 7200 rpm 1800 rpm 5-16
P0136 Addition on the manual torque curve
(IxR)
0 to 100 0 5-17
P0137 Addition on the automatic torque curve 0 to 1000 0 5-18
P0138
(2)
Rated slip -10.00 to 10.00 % 0.00 % 5-19
P0139 Output current ļ¬lter 0.0 to 16.0 s 0.2 s 5-20
P0140 Redundant ventilation selection 0 = Inactive
1 = Set A
2 = Set B
3 = Alternating A
4 = Alternating B
0 5-21
P0141 Number of hours for alternating ventila-
tion set
1 to 9999 h 720 h 5-21
P0142
(1)
Maximum Voltage 0.0 to 100.0 % 100.0 % 5-22
P0143
(1)
Intermediate output voltage 0.0 to 100.0 % 50.0 % 5-22
P0144
(1)
Output voltage at 3 Hz 0.0 to 100.0 % 8.0 % 5-22
P0145
(1)(2)
Field weakening speed 0 to 7200 rpm 1800 rpm 5-22
P0146
(1)(2)
Intermediate speed 90 to 7200 rpm 900 rpm 5-22
P0151
(4)
DC Link voltage regulation actuation
level
106 to 1200 V 1118 V 5-23
P0152 Proportional gain of the DC link voltage
regulator
0.00 to 9.99 0.00 5-24
P0156
(2)(5)
Overload current at 100 % 0.0 to 3420.0 A 154.0 A 5-24
P0157
(2)(5)
Overload current at 50 % 0.0 to 3420.0 A 126.0 A 5-24
P0158
(2)(5)
Overload current at 5 % 0.0 to 3420.0 A 70.0 A 5-24
P0159 Temperature alarm I x t 0 to 100 % 80 % 5-25
P0161 Speed regulator proportional gain 0.0 to 200.0 20.0 5-26
P0162 Integration constant of the speed regu-
lator
1 to 9999 100 5-26
P0163 Local reference offset -999 to 999 0 5-26
P0164 Remote reference offset -999 to 999 0 5-26
P0165 Time constant of the measured speed
ļ¬lter
0.001 to 1.000 s 0.012 s 5-26
P0167 Current regulator proportional gain 0.000 to 9.999 0.080 5-26
P0168 Current regulator Integral gain 0.1 to 999.9 12.3 5-26
P0169
(5)
Maximum output current 0.0 to 510.0 A 161.0 A 5-27
MVW3000 | 1-3
