4
HMI OPERATION
Exit 13:38
In Ref.
LOC
1800rpm
S Status
D Diagnostics
C Configurations
Select
Exit 13:38
In Ref.
LOC
1800rpm
C1 HMI
C2 Ramps
C3 Control
C4 Nominal data
C5 Commands
C6 I/O
Select
Exit 13:38
In Ref.
LOC
1800rpm
C1.1 Language
C1.2 Password
C1.3 Main screen
C1.4 Trend
C1.5 Settings
Select
Figure 4.5: Menu, submenu and subsubmenu (level 1, 2 and 3)
Table 4.2: Groups accessed through the main menu
Menu
Parameters or Submenu to which access is given
Status
Allows viewing of the MVW3000 reading variables.
Diagnostics
It allows viewing variables and events that may help diagnose problems or improve the MVW3000
operation.
Configurations
This menu allows the programming of all MVW3000 configuration parameters.
In the navigation modes, a scrollbar appears at the HMI left side, with the purpose of helping the navigation by
signalizing the relative position of the cursor regarding the total of possible groups/parameters.
4.3 PARAMETER EDITION
The activation of the edition or parameter changing is executed by pressing the key or the softkey associated
to the parameter navigation.
Once in edition mode, if the softkey [Exit] is used, the modifications are not stored in the parameter memory and
the value prior to the edition is restored. In a similar way, using the softkey [Save], the new parameter content is
stored in inverter parameter memory.
4.3.1 Numerical edition
The numerical parameters are changed with the and keys to increment and decrement their contents.
It is possible changing the parameter contents with a ten times faster (x10) rate; the and keys are used to
increment/decrement the tens.
Exit 13:38 Save
Motor Rdy
LOC
1800rpm
P0100
Acceleration Time
180.0
s
Figure 4.6: Numerical edition
MVW3000 | 4-6
