5
DETAILED PARAMETER DESCRIPTION
Table 5.8: Selection of JOG command via digital input
JOG key
Digital inputs DI1 to DI3
(P0255 = 2 and/or P0228 = 2)
DI3 - P0265 = JOG or
DI4 - P0266 = JOG or
DI5 - P0267 = JOG or
DI6 - P0268 = JOG or
DI7 - P0269 = JOG or
DI8 - P0270 = JOG or
DI9 - P0271 = JOG or
P0225 = 1 and/or P0228 = 1
DI10 - P0272 = JOG
When activating the JOG function, the motor will accelerate until reaching the value defined in P0122, following
the adjusted ramp.
The direction of rotation is defined by the direction of rotation function (P0223 or P0226).
The JOG command is only effective with the motor stopped.
Activation of JOG + function:
Table 5.9: Selection of JOG + command
Digital Inputs
Parameters
DI3 to DI10
P0265 to P0272 = JOG +
Activation of JOG - function:
Table 5.10: Selection of JOG - command
Digital Inputs
Parameters
DI3 to DI10
P0265 to P0272 = JOG-
When activating the JOG+/JOG- function, the speed reference in P0122/P0123 will be added (without ramp)
to the other references to generate the total reference - see Figure 5.23 on page 5-39.
P0124 - Multispeed reference 1
P0125 - Multispeed reference 2
P0126 - Multispeed reference 3
P0127 - Multispeed reference 4
P0128 - Multispeed reference 5
P0129 - Multispeed reference 6
P0130 - Multispeed reference 7
P0131 - Multispeed reference 8
Adjustable range: 0 to 4095 rpm Factory setting: P0124 = 90 rpm
P0125 = 300 rpm
P0126 = 600 rpm
P0127 = 900 rpm
P0128 = 1200 rpm
P0129 = 1500 rpm
P0130 = 1800 rpm
P0131 = 1650 rpm
Acesso: Menu → Configurations → Control
Description:
These parameters (P0124 to P0131) will only be displayed when P0221 = 8 and/or P0222 = 8 (Multispeed
(P0124 to P0131)).
MVW3000 | 5-14
