5
DETAILED PARAMETER DESCRIPTION
P0255 - AO3 Function
Adjustable range: 0 to 21 Factory setting: 2
Acesso: Menu Configurations I/O Analog outputs
Description:
With factory default values (P0255 = 2 and P0256 = 1.000) AO3 = 10 V when Actual Speed = Maximum speed
reference (P0134).
Refer to Table 5.43 on page 5-52 for further details regarding the functions of the analog outputs.
For information on the AO3 output, refer to Chapter 7 OPTIONAL ACCESSORIES AND BOARDS on page 7-1
of the User’s Manual.
P0256 - Analog output AO3 gain (EBA board)
Adjustable range: 0.000 to 9.999 Factory setting: 1.000
Acesso: Menu Configurations I/O Analog outputs
Description:
It sets the gain of analog output AO3. For P0256 = 1.000 the output value of AO3 is set according to the
description “analog output indication scale” in P0262.
P0257 - AO4 Function
Adjustable range: 0 to 21 Factory setting: 5
Acesso: Menu Configurations I/O Analog outputs
Description:
For values in the factory default (P0257 = 5 and P0258 = 1.000) AO1 = 10 V when Motor Current = 1.5 x P0295.
See Table 5.43 on page 5-52 for further details related to the function of analog outputs.
For information on the AO4 output, refer to Chapter 7 OPTIONAL ACCESSORIES AND BOARDS on page 7-1
of the User’s Manual.
P0258 - Analog output AO4 gain (EBA board)
Adjustable range: 0.000 to 9.999 Factory setting: 1.000
Acesso: Menu Configurations I/O Analog outputs
Description:
It sets the gain of analog output AO4. For P0258 = 1.000 the output value of AO4 is set according to the
description “analog output indication scale” in P0262.
P0259 - AO5 Function
Adjustable range: 0 to 21 Factory setting: 2
Acesso: Menu Configurations I/O Analog outputs
Description:
For values in the factory default (P0259 = 2 and P0260 = 1.000) AO5 = 20 mA when Actual Speed = Maximum
speed reference (P0134).
See Table 5.43 on page 5-52 for further details related to the function of analog outputs.
MVW3000 | 5-51
