WEG MVW3000 User Manual

5
DETAILED PARAMETER DESCRIPTION
P0260 - Analog output AO5 gain (unipolar isolated MVC4 board)
Adjustable range: 0.000 to 9.999 Factory setting: 1.000
Acesso: Menu → Configurations → I/O → Analog outputs
Description:
It sets the gain of analog output AO4. For P0260 = 1.000 the output value of AO5 is set according to the
description “analog output indication scale” in P0262.
P0261 - AO6 Function
Adjustable range: 0 to 21 Factory setting: 5
Acesso: Menu → Configurations → I/O → Analog outputs
Description:
For values in the factory default (P0261 = 5 and P0262 = 1.000) AO5 = 20 mA when Motor Current = 1.5 x P0295.
See Table 5.43 on page 5-52 for further details related to the function of analog outputs.
P0262 - Analog output AO6 gain (unipolar isolated MVC4 board)
Adjustable range: 0.000 to 9.999 Factory setting: 1.000
Acesso: Menu → Configurations → I/O → Analog outputs
Description:
It sets the gain of analog output AO6. For P0262 = 1.000 the output value of AO6 is set according to the
description “analog output indication scale” in P0262.
Table 5.43: Analog output functions
Function
P0251
(AO1)
P0253
(AO2)
P0255
(AO3)
P0257
(AO4)
P0259
(AO5)
P0261
(AO6)
Full scale (10V)
Speed reference
0 0 0 0 0 0
1 x P0134
Total reference
1 1 1 1 1 1
1 x P0134
Actual speed
2 2 2 2 2 2
1 x P0134
Not used
3/4 3/4 3/4 3/4 3/4 3/4
Output current (with filter 0.5 s)
5 5 5 5 5 5
1,5 x P0295
PID process variable
6 6 6 6 6 6
1 x P0528
Active output current
7 7 7 7 7 7
100 % P0295/P0401
Output power
8 8 8 8 8 8
2,0 x P0295 x P0296 x
√
3
PID reference
9 9 9 9 9 9
1 x P0528
Not used
10 10 10 10 10 10
Trace channel 1 to 8
11 a
18
11 a
18
11 a
18
11 a
18
11 a
18
11 a
18
The same as the one of
the chosen parameter
Inverter temperature
19 19 19 19 19 19
200 °C
PLC
20 20 20 20 20 20
Output voltage
21 21 21 21 21 21
1 x P0296
MVW3000 | 5-52
