5
DETAILED PARAMETER DESCRIPTION
P0296 - Inverter rated voltage
Adjustable range: 0 to 14 Factory setting: 14
Acesso: Menu → Configurations → Nominal data → Inverter
Description:
It defines the inverter rated voltage according to the available models.
WARNING!
Adjust P0296 according to the output voltage to be used!
Table 5.47: Inverter rated voltage
P0296 Function
0
1150 V
1
2300 V
2
3300 V
3
4160 V
4
5500 V
5
6300 V
6
6900 V
7
7200 V
8
8000 V
9
9000 V
10
10000 V
11
11000 V
12
12000 V
13
13200 V
14
13800 V
✓
NOTE!
This parameter can be changed only with the motor stopped.
P0303 - Skipped Speed 1
P0304 - Skipped Speed 2
P0305 - Skipped Speed 3
P0306 - Skipped Range
Adjustable range: P0303 = 0 to 4095 rpm
P0304 = 0 to 4095 rpm
P0305 = 0 to 4095 rpm
P0306 = 0 to 750 rpm
Factory setting: P0303 = 600 rpm
P0304 = 900 rpm
P0305 = 1200 rpm
P0306 = 0 rpm
Acesso: Menu → Configurations → Protections
Description:
It avoids permanent motor operation at speeds in which, for instance, the mechanical system enters into
resonance causing high vibration or noise levels.
The passage through the skipped range (2 x P0306) occurs through the acceleration and deceleration ramps.
The function does not operate properly if two bands of skipped speed overlap.
MVW3000 | 5-66
