5
DETAILED PARAMETER DESCRIPTION
P0305
P0304
P0303
P0305
P0304
P0303
Speed reference
2 x P0306
2 x P0306
Motor speed
Figure 5.38: Skipped speed curve
P0308 - Serial address
Adjustable range: 1 to 30 Factory setting: 1
Acesso: Menu Configurations Communications
Description:
It sets the inverter address for serial communication.
Refer to Section 9.2 SERIAL WEGBUS on page 9-12 of the User’s Manual.
NOTE!
This parameter can be changed only with the motor stopped.
P0309 - Fieldbus
Adjustable range: 0 to 13 Factory setting: 0
Acesso: Menu Configurations Communications
Description:
0 = Inactive Fieldbus.
1 to 6 = define the Fieldbus standard to be used (Profibus DP or DeviceNet) and the number of variables to be
exchanged with the master.
It is only applicable for the Profibus DP or DeviceNet optional kits.
For P0309 = 10, refer to the DeviceNet Drive Profile Guide.
MVW3000 | 5-67
