5
DETAILED PARAMETER DESCRIPTION
P0018 - Value of analog input AI1 (single-pole, MVC4 board)
P0019 - Value of analog input AI2 (two-pole, MVC4 board)
P0020 - Value of analog input AI3 (two-pole, EBB board)
P0021 - Value of analog input AI4 (two-pole, EBA board)
Acesso: Menu → Status → I/O → Analog
Description:
They indicate the values of analog inputs AI1 and AI2 of the MVC4 control board, AI3 of the EBB board and
AI4 of the EBA board in percentage of the full scale.
The indicated values are obtained after addition of the offset and multiplication by the gain.
See the description of parameters P0234 (Analog input AI1 gain (unipolar MVC4 board)) to P0247 (Analog
input AI4 offset (bipolar EBA board)).
Analog input AI2 has a filter that distinguishes it from others (see P0248 (Analog input AI2 filter (bipolar MVC4
board))).
P0022 - Temperature on MVC3 board
Acesso: Menu → Status → Measurements → Temperature
Description:
It indicates the temperature value on the MVC3 control board in degrees Celsius (°C).
P0023 - MVC4 board software version
Acesso: Menu → Status → Inverter → Software version
Description:
It indicates the software version contained in the microcontroller memory located on the MVC4 control board.
P0025 - Iv
P0026 - Iw
P0027 - Iu
Acesso: Menu → Status → I/O → Analog
Description:
Indicate the result of the A/D conversion, in module, of the phase current.
P0028 - Value of analog input AI5 (isolated single-pole, MVC4 board)
Acesso: Menu → Status → I/O → Analog
Description:
It indicates the value of analog input AI5 of the MVC4 control board in percentage of full scale. The indicated
values are obtained by means of addition of the offset and multiplication by the gain.
See description of parameters P0721 to P0724.
MVW3000 | 5-6
