1
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0269
(1)
DI7 Function 0 = Not Used
1 = Local/Remote
2 = General Enable
3 = JOG
4 = No External Fault
5 = Reserved
6 = Ramp 2
7 = Reserved
8 = Stop
9 = Reserved
10 = JOG+
11 = JOG-
12 = Reset
13 = Fieldbus
14 = 3 Wire Start
15 = Manual/Automatic
16 = Reserved
17 = Reserved
18 = Reserved
19 = Parameterization Disabling
20 = Reserved
21 = RL2 Timer
22 = RL3 Timer
23 = Initiates Synchronous Transfer
24 = Ventilation OK
0 5-54
P0270
(1)
DI8 Function 0 = Not Used
1 = Local/Remote
2 = General Enable
3 = JOG
4 = No External Fault
5 = Reserved
6 = Ramp 2
7 = Reserved
8 = Stop
9 = Reserved
10 = JOG +
11 = JOG -
12 = Reset
13 = Fieldbus
14 = 3 Wire Stop
15 = Manual/Automatic
16 = Motor Thermistor
17 = Reserved
18 = Reserved
19 = Parameterization Disabling
20 = Reserved
21 = RL2 Timer
22 = RL3 Timer
23 = Initiates Synchronous Transfer
24 = Ventilation OK
0 5-54
MVW3000 | 1-12
