6
SPECIAL FUNCTIONS
P0221/P0222 = 0 (Setpoint by keys)Note 1:
P0221/P0222 = 1 to 11Note 2:
Academic
PID
Setpoint Denition (process
variable reference)
P0525
Note 1
Note 2
Setpoint
Enable
Enable
P0520
P0521
P0522
Academic PID
+
+
+
+
P0040
Conguration P0524
AI2'
AI3'
P0526
P0133, P0134
1 = Reverse
0 = Forward
Action type of the PID regulator
P0527
Inverter speed
reference
Manual
Inverter
speed
reference
Automatic
DI3
(P0265 = 15)
P0523
(DIx open)
(DIx closed)
(Setpoint via analog inputs, multispeed, serial, eldbus, PLC)
Figure 6.1: Academic PID regulator block diagram
MVW3000 | 6-3
