11
ELECTRICAL SYSTEM DRAWING FOR WP12 MARINE DIESEL ENGINE
Monito
r
Water Temp, Sensor
Engine Speed Sensor
24V
Battery
Battery
+
-
Oil Temp, Sensor
Oil Pressure Sensor
Generator Schematic Diagram
Generator
Generator Schematic Diagram
Engine Wiring Diagram
Generator
Starter
D1
50
30
31
M
D+
B+D+
DF
Regulator
30
50
B+
B-
D+
W
W
W
V
U
G
31
D2 D3 D4 D5 D6
Starter
Pin D1
Starter
Pin D2
Starter
Pin D6
Generator
Pin D3
Generator
Pin D5
Alarm
Pin D4
-
+
Starter Motor

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the WEICHAI WP12 and is the answer not in the manual?

WEICHAI WP12 Specifications

General IconGeneral
Engine ModelWP12
Number of Cylinders6
Displacement11.596 L
Bore x Stroke126 mm x 155 mm
Compression Ratio17:1
Max Torque2100N.m
Weight1100 kg
Fuel SystemHigh Pressure Common Rail
Fuel Consumption≤195g/kWh
