WEICHAI WP12 User Manual

35
Open the inspection window on the ywheel and match the OT mark to the pointer
(Refer gure 5.19).
0
Figure 5.19
Check and conrm compression TDC of the 1st cylinder. Adjust the Clearance in
the following order. (Refer gure 5.20 & 5.21)
CYL. NO 1 2 3 4 5 6
STEP- 1 I E I - - E I - - E - -
Figure 5.20 Figure 5.21
Rotate the engine 360° - match the OT mark to the pointer. Adjust the
clearance in the following order. (Refer gure 5.22).

WEICHAI WP12 Specifications

General

Engine Model	WP12
Number of Cylinders	6
Displacement	11.596 L
Bore x Stroke	126 mm x 155 mm
Compression Ratio	17:1
Max Torque	2100N.m
Weight	1100 kg
Fuel System	High Pressure Common Rail
Fuel Consumption	≤195g/kWh
