WEICHAI WP12 User Manual

51
Premixed READY TO USE antifreeze engine coolant is recommended to use as is
condition, as a FIRST FILL as well as for TOP UP of the cooling system.
Refer table 6.6 to select the best suitable coolant solution
GENERAL SPECIFICATION FOR COOLANT
PARAMETER STANDARD JFL318 JFL-336 JFL-336
1. Glycol content % 33 50 56
2. Specic weight(15.6°C) 1.05 1.074 1.082
3. Boiling Point(°C) 104.5±1 108.5±1 110.0±1
4. Freezing Point(°C) -18±1 -36±1 -45±1
5. Minimum temperature for
application(°C)
-10 -26 -35
Table 6.6

WEICHAI WP12 Specifications

General

Engine Model	WP12
Number of Cylinders	6
Displacement	11.596 L
Bore x Stroke	126 mm x 155 mm
Compression Ratio	17:1
Max Torque	2100N.m
Weight	1100 kg
Fuel System	High Pressure Common Rail
Fuel Consumption	≤195g/kWh
