25
ProCommander
®
AX Pin Assignment
ATTENTION!
The maximum current per output must not exceed
500mA. Do not use inbound power supplies of
higher than 24VDC.
LINE OUT
An external audio amplifier can be connected to the line-out
outputs of the ProCommander
®
AX. A parallel operation with
the internal amplifier is possible under certain conditions, and
depends on the connected external amplifier. If necessary, the
function must be proven if it works properly.
LS-OUT
The ProCommander
®
AX has a built in 2x20W Class D
amplifier. At the two outputs LS-L (left channel) and LS-R (right
channel), either 4-ohm or 8-ohm speakers may be connected.
