WEIGL ProCommander AX - ProCommander AX Rear Panel

20
ProCommander
®
AX Pin Assignment
3.2 ProCommander
®
AX REAR
3.2.1 Pin assignment REAR
Rel 1
1N40 07
D1
1
1
2
2
3
4
R E LA Y 1
Rel 1
1N40 07
D1
1
1
2
2
3
4
R E LA Y 4
4/8 Oh m
4/8 Oh m
LE FT +
LE FT -
RIG H T +
RIG H T -
DIGITAL IN 5 PS+: 12V-24 V D IGI TA L I N 6 D IGI TA L I N 7
D IGI TA L I N 8
ma x. 500mA/24 V ma x. 500mA/24 V
ALWAYS MOUNT FLYBACK DIODE IN RE VERSE
DIRECTION PARA LLEL TO EACH INDUCTIVE LOAD!
GND
REAR WIRING DIAGRAM for ProCommander
®
AX
PS+: 12V-24 V/ma x. 96Wa tt
PS: GND
EXTERNAL POWER S UPPLY +
EXTERNAL AUDIO-AMP LI FIER
ALWAYS TAKE CARE OF
POWER POLARITY!
RS485/ CAN
ANAL OG OUT 1 ANAL OG OUT 4
ma x. 10mA
0-10V
ANALOG IN 1
(0-10V)
ANALOG IN 1/ D IGI TA L I N 1 ANALOG IN 2/ D IGI TA L I N 2 ANALOG IN 3/ D IGI TA L I N 3 ANALOG IN 4/ D IGI TA L I N 4
ANALOG IN 4
(0-10V)
max. 24V DC
INPUT CI RCUIT IN1-IN4
IN1 -IN4
4K7
R2
10K
R1
D1
ZD3V 3
2
1
1
1
2
2
TO_IN 1-4
INPUT CI RCUIT IN1-IN4
IN1 -IN4
4K7
R2
10K
R1
D1
ZD3V 3
2
1
1
1
2
2
TO_IN 1-4
The pin assignment
of the IX connector
can be found on a
separate page in this
wiring diagram!
ATTENTION!
IX Connector Type A
ATTENTION!
For a higher resolution, please download the
wiring diagram from Weigl Support and Solutions
Center.
POWER
The ProCommander
®
AX can be operated with voltages
from 12V to 24V/ max. 96Watt (for class-2 installations).
