Analog MIN- and MAX-value
6 Analog MIN- and MAX-value
For each of the four 0-10V analog-channels, the four servo-
channels, as well as for the four PWM-channels a minimum and
maximum value can be adjusted.
So the voltage range, servohub or the PWM-value can be
circumscribed. Hereby, it is important to consider that after the
start-up all four analog-values have the voltage level 0V. The
eventually adjusted minimum value will be set at the output
immediately after the booting of the ProCommander® AX. This
takes a few milliseconds.
!san…# is the command for the minimum level. The
resolution of values is in 0.01%-steps from 0 to 10000. The
command !san1=1055# sets for the analog-channel 1 to a
minimum value of 10.55%. The minimum value must not be
higher than the maximum value. If a higher value will be entered
the minimum value will be set to the adjusted maximum value.
In this case, the analog-output remains at the adjusted value.
!sax…# adjust the maximum value, whereby the same
criteria as for the minimum value apply. The resolution is also in
0.01% steps from 0-10000 and the maximum value must not be
less than the minimal value. !sax2=9023# sets for the analog-
channel 2 the maximum value to 90.23%. The maximum value
must not be lower than the minimum value. If a lower value is
entered, the maximum value will be set to the level of minimum
value.
!qmm# lists all channels with their min and max values at
once.
