Programming the ProCommander
®
AX
11 Network Connection Communication
11.1 Network Connection between
ProCommander
®
AX and Pro I/O
TM
The ProCommander
®
AX commands an intern chart, which
associate each "Sub-Device-ID" of a Pro I/O
TM
module with an
IP address.
By default for all modules broadcast addresses are adjusted,
which read in all commands, independently of the adjusted
IP address of the Pro I/O
TM
modules. Because of the Sub-Net
address adjustment (A1, A2, …) of a device, each Pro I/O
TM
module analyze only the own commands.
If it's necessary to assign individual IP addresses, so that
conflicts with other devices in the network can be avoided, the
values of the charts can be modified.
Two commands are available for that. On the one hand the
global command !swi…# and on the other hand the individual
command !spi…#.
With !swi…# a consecutive numbering takes place for all
Pro I/O
TM
modules, beginning with the entered start-IP address.
With !spi…# each module can be assigned to an individual
address. These commands can be assigned via the configurator.
!spp1=22202# sets the port of the Sub-Device-ID with the
ID 1 to 22202.
!gpo1# gets the port of the Sub-Device-ID 1.
