WEIGL ProCommander AX - Default Chapter; Table of Contents

Table Of Contents
1 Important Information and Safety Tips .5
1.1 FCC and CE Compliance .............................8
1.2 FCC Instruction to User ............................... 8
1.3 FCC DECLARATION OF CONFORMITY....10
1.4 CE DECLARATION OF CONFORMITY ...... 11
2 Warranty ...............................................13
3 ProCommander
®
AX Pin Assignment ..15
3.1 ProCommander
®
AX FRONT ....................15
3.1.1 Pin assignment FRONT .......................15
3.2 ProCommander
®
AX REAR ....................... 18
3.2.1 Pin assignment REAR .......................... 18
3.3 ProCommander
®
AX REAR Gecko (Vendor
specific, special order) ..............................21
3.3.1 Pin assignment REAR Gecko .............. 21
3.4 ProCommander
®
AX Display ....................24
3.4.1 ProCommander
®
AX Outputs .............24
3.4.2 ProCommander
®
AX Sub-Device-ID ...25
3.4.3 ProCommander
®
AX Loudspeaker ..... 26
4 ProCommander
®
AX Update .................27
4.1 ProCommander
®
AX Firmware Update ...27
4.2 Wi-Fi Module Firmware Update ................ 33
5 ProCommander
®
AX Wi-Fi
Configuration .......................................41
5.1 Setup Wi-Fi Configuration .........................41
5.2 Network Configuration ..............................43
5.2.1 WLAN IP Address Configuration ........43
5.3 Tunnel Configuration .................................44
5.4 WLAN Profile Configuration ...................... 45
6 Analog MIN- and MAX-value ...............47
