WEIGL ProCommander AX - Page 5

12.4 Wi-Fi Module Specification .......................78
12.4.1 Network ................................................78
12.4.2 Security & Authentication ..................78
12.4.3 Certifications & Compliance ...............78
12.5 Pin assignment IX Connector - RS485/
CAN ............................................................79
12.6 Pin assignment ProCommander
®
AX
GECKO - GECKO connector......................80
12.7 Assignment ProCommander
®
AX - Analog
IN 1-4/ Digital IN 1-8, Analog OUT 1-4 /
Digital OUT/ PWM 1-4 (Pin 5-8) ................81
12.8 Assignment ProCommander
®
AX GECKO
- Digital IN 5-8 (Pin 1-4), Digital OUT/ PWM
1-4 ............................................................... 82
12.9 Pin assignment LS (Loudspeaker) ........... 83
13 Glossary ................................................85
14 F.A.Q. ...................................................87
15 Index .....................................................89
