Important Information and Safety Tips
ProCommander
®
AX or connected components.
Only experienced personnel should connect the
ProCommander
®
AX to other systems and only do so such that
they comply with required safety regulations.
ATTENTION!
Please ensure that all cables from and to the
ProCommander
®
are laid carefully and that they
aren't damaged at any time.
ATTENTION!
External power sources connected to the
ProCommander
®
must not exceed the maximum
allowable voltage (24V) and must be protected
accordingly. In addition, correct polarity must be
utilized to avoid damage to the ProCommander
®
.
Failure to do so will void the warranty and Weigl
GmbH & Co KG or Weigl Works, LLC will not be liable
for any resulting damages.
When connecting solenoids, a freewheeling diode for each
solenoid is required. They should be mounted as close as
possible to the solenoid. Please refer to the wiring diagram in
the manual. If this is not observed, the output driver will be
destroyed, thus voiding the warranty.
