Weishaupt WG10 Series User Manual

Installation and operating instruction
Gas burner WG10…/0-D ZM-LN
6 Operation
83300902 1/2019-02 La
33-112
6.2.1 Info level
Burner data can be interrogated in the Info level .
Press [Enter] for approx. 0.5 seconds.
The Info level is activated.
Press [Enter] to reach the next information.
l,m³
No. Information
0 Total gas consumption in m
3
(via X3:8)
Reset value:
Press [L/A] and [+] simultaneously for approx. 2 seconds.
1 Hours run
2 – no function –
3 Burner starts
4 Device item number
5 Index of device item number
6 Device number
7 Production date (DDMMYY)
8 Fieldbus address
9 Valve proving behaviour
11 Not used
12 Current gas consumption (0.1 m
3
/h)
13 Analogue module EM3/3 or Fieldbus module EM3/2 available
0: no
1: yes
After information13 or a waiting time of approx. 20 seconds the combustion man-
ager changes over to the operating level.
