Installation and operating instruction
Gas burner WG10…/0-D ZM-LN
9 Servicing
83300902 1/2019-02 La
70-112
9.6 Service position
Observe notes on servicing [ch.9.1].
The burner mounted rotated by 180° cannot be placed into the service position.
Remove mixing head [ch.9.3].
Remove cover2 and remove plugs.
Hold housing cover and remove screws1.
Place housing cover onto hanging bolts3.
