Installation and operating instruction
Gas burner WG10…/0-D ZM-LN
6 Operation
83300902 1/2019-02 La
36-112
Pno. Parameters Setting range Factory
setting
E Display mode 0: E-parameter is not activated in the access level
1: E-parameter is activated in the access level
Settings 2 and 3 are required for O2 trim, see supplementary
sheet O2 trim W burners (Print No.835587xx).
0
F Restart attempts following
flame failure
0 … 1 1
H Actuator setting for post-purge 0.0 … 90.0°
Change air damper setting:
Press [L/A] and [+] or [–].
0
L Load shutdown 0.0 … 4095 seconds
If there is no longer a demand for heat, the W-FM reduces
the burner capacity and closes the fuel valves after the time
set has elapsed. If partial load is reached before the time
has elapsed, the fuel valves close immediately.
0
n Operating mode O2 trim (only
in conjunction with O2 trim)
0: not activated
Additional parameters can be displayed with setting 1 … 4,
see supplementary sheet O2 trim W burners
(Print No.835587xx).
0
After the last parameter or a waiting time of approx. 20 seconds the combustion
manager changes over to the operating level.
