Welch Allyn 5300P Directions For Use

10 Chapter 1 General Information Welch Allyn Vital Signs Monitor 300 Series
Connections
For information on the connections, refer to the following:
AC Power Adapter “Connecting AC Power” on page 11
Temperature Probe “Connecting the Temperature Probe Cable” on page 14
SpO
2
Sensor “Connecting and Disconnecting the SpO
2
Sensor Cable” on page 15
NIBP Cuff Hose “Connecting the NIBP Cuff Hose” on page 13
Nurse Call Cable “Nurse Call” on page 81
30V , 1A Max.
Temperature Probe
Cable Connector
SpO
2
Sensor Cable
Connector
DC Power Cable
Connector
RS232 Cable
Connector
Nurse Call Cable
Connector
SpO
2
