Directions for Use Chapter 2 Setup 13
Connecting the NIBP Cuff Hose
Attach the hose to the monitor and the cuff as follows, referring to the illustration below:
1. Screw the hose connector onto the NIBP connector on the monitor.
2. Connect the monitor hose connector to the mating connector on the cuff.
For information on NIBP measurements, see “Patient Monitoring” on page 31.
Threaded NIBP
Hose Connector
