Welch Allyn 5300P Directions For Use

Directions for Use Chapter 2 Setup 29
Selecting Stream or Batch Printing
Default setting: BATCH.
For monitors configured with the optional thermal printer:
1. Press and hold for three seconds.
2. Press until the message window reads PRINT: BATCH or PRINT: STREAM.
3. Press or to alternate between PRINT: BATCH and PRINT: STREAM display.
4. To set the displayed printing method and return to normal operation, do nothing for 10
seconds or press any key other than or . If you press a function button (such as
), the monitor returns to normal operation with that function ( ) activated.
For information on using the printer, see “Patient Monitoring” on page 31.
SYS
DIA
SpO2 %
/min
ºC
ºC
M
kPa
PRINT: STREAM
SYS
DIA
SpO2 %
/min
ºC
ºC
M
kPa
PRINT: BATCH

Welch Allyn 5300P Specifications

General

Brand	Welch Allyn
Model	5300P
Category	Medical Equipment
Language	English
