Welch Allyn Atlas Service Manual

Section 2 - Service
SERVICE MANUAL 6200-43E REV. A WELCH ALLYN ATLAS MONITOR 1
2.1 Incoming Inspection
o 2.1.1 Inspect shipping package and product
for damage. Make a record of possible
shipping damage.
2.1.2 List accessories in box.
o power cord
o SpO
2
probe
o ECG leads
o ECG lead cable
o Cuff(s)
o Operator Manual
o nasal C0
2
Line
o ECG Electrode(s)
o temperature probe
o BP tubing
o paper
o loose parts, describe
o 2.1.3 Clean and disinfect by following the
instructions printed in the Operator
Manual.
o 2.1.4 Operate the Atlas to verify the customer
complaint before making any changes to
the unit. Call the customer if the complaint
is unclear.
NOTE: Perform REPAIR TESTS in
Section 2.2 to fully inspect the
Atlas monitor before and after
servicing. Refer to Section 3
for Troubleshooting help.
2.1.5 If the unit has caused or is suspected of
having caused an injury of any type:
DO NOT DISASSEMBLE OR REPAIR
THE UN IT IN ANY WAY.
Contact Welch Allyn Customer Service
immediately.
Service Intervals for
Calibration and Main-
tenance are listed in
Atlas Operator’s
Manual Appendix C.
