Welch Allyn Atlas Service Manual

Appendix B
Atlas Repair Parts
Part Number
Description
6200-43E
SERVICE MANUAL
620001-501
MAIN PCB ASSY - LOW END
620004-501
ATLAS CPU PCB ASSY
620007-501
FRONT PANEL DISPLAY PCB ASSY
620013-501
PRINTER PCB
620016-501
MAIN PCB ASSY - MID/HIGH END
620032
ETCO2 PCB ASSY
620034
ETCO2 CONNECTOR & CABLE
620035
NELLCOR SPO2 BD
620038
NELLCOR LABEL (CARTON)
620105-1
BATTERY DOOR
620117
PRINTER DOOR BUTTON
620119
LATCH SPO2
620125-501
MAIN CASE/HANDLE SET
620126-6
BEZEL SET/HIGH HEAT TRANSFER
620127
METAL BRACKET FOR PRINT
620131-1
MAIN FOAM
620132-2
TOP FOAM
620133
BP FOAM
620134-501
GEAR ASSY
620138-501
PRINTER DOOR ASSY
620139-501
PRINTER FRAME ASSE
620140-501
MAIN PRINTER ASSY
620141
METAL HOUSING - TOP
620142-1
METAL HOUSING-BOTTOM (LG)
620143
NUT TEMPERATURE
620144
BRACKET SPO2
620148
GASKET CO2 EXHAUST
620149
FITTING,1/16 X 1/8-27 NPT
620150-1
AC/DC POWER SUPPLY
620159
PRINT HEAD
620165
CABLE-CONN TO MAIN BD,ECG
620167
CABLE-MAIN BD TO DISPLAY BD
620168-1
CABLE ASSY POWER SUPPLY
620169-2
CABLE ASSY NELLCOR SENSOR
620170
CABLE ASSY NELLCOR
620171
CABLE ASSY SPEAKER
620172-2
CABLE ASSY AC
620173
CABLE-TEMP SENSOR TO MAIN
620175
CABLE ASSY - FAN
620176
CABLE ASSY - PRINTER
620177
CABLE ASSY - PRINT HEAD
620178
CABLE ASSY SP02
620182
LABEL - RS232
620187-501
PNEUMATIC SUB ASSY
620189
4-20 X 5/16 SLT/TORX PN PL ZIN
620192
PNEUMATIC CONNECTOR (MACH)
620193
NUT, HEX 5/16-32 X.095 PNEUM
620194
WASHER,FLT.33 X.62 X.049
620197
BUSHING, SPLIT NYLON
620198
FOOT
620200-501
CRT SUB ASY
Page 1
